VTWS-227、VTWS-232固定螺钉锁定

孔径

型号

轴承芯-件编号

基本动

态额定载荷

磅/牛

尺寸（英寸/毫米）VTWS 200 系列标准型宽槽滑块单元 － 固定螺钉锁定

重量磅/

公斤

A

B

C

D

F

G

H

芯

J

K

L

N

O

P

毂

R

S

T

英寸

1/2

5/8

VTWS-208

VTWS-210

VS-208

VS-210

2108

9377

2-11/16

68.3

5/8

15.9

2

50.8

3-11/16

93.7

1-7/8

47.6

1-1/4

31.8

3/4

19.1

1-1/32

26.2

5/8

15.9

31/32

24.6

3

76.2

3-1/2

88.9

1-3/8

34.9

1-5/16

33.3

1-3/8

34.9

17/32

13.5

1.5

.68

3/4

VTWS-212

VS-212

2611

11614

3

76.2

5/8

15.9

2-1/4

57.2

4

101.6

1-7/8

47.6

1-1/4

31.8

3/4

19.1

1-7/32

31.0

23/32

18.3

1-3/16

30.2

3

76.2

3-1/2

88.9

1-3/8

34.9

1-7/16

36.5

1-9/16

39.7

17/32

13.5

1.7

.77

7/8

15/16

1

VTWS-214

VTWS-215

VTWS-216

VS-214

VS-215

VS-216

2801

12459

3-5/64

78.2

5/8

15.9

2-1/4

57.2

4-3/32

104.0

1-7/8

47.6

1-1/4

31.8

3/4

19.1

1-3/8

34.9

13/16

20.6

1-3/8

34.9

3

76.2

3-1/2

88.9

1-1/2

38.1

1-9/16

39.7

1-17/32

38.9

17/32

13.5

1.6

.73

1-1/8

1-3/16

VTWS-218

VTWS-219

VS-218

VS-219

4381

19487

3-3/8

85.7

3/4

19.1

2-1/2

63.5

4-5/8

117.5

2-1/8

54.0

1-7/16

36.5

7/8

22.2

1-1/2

38.1

7/8

22.2

1-19/32

40.5

3-1/2

88.9

4

101.6

1-3/4

44.5

1-25/32

45.2

1-19/32

40.5

17/32

13.5

2.4

1.09

1-1/4

1-3/8

1-7/16

VTWS-220

VTWS-222

VTWS-223

VS-220

VS-222

VS-223

5782

25718

3-3/4

95.3

3/4

19.1

2-3/4

69.9

5

127.0

2-1/8

54.0

1-7/16

36.5

7/8

22.2

1-11/16

42.9

1

25.4

1-55/64

47.2

3-1/2

88.9

4

101.6

1-3/4

44.5

2

50.8

1-3/4

44.5

17/32

13.5

3.3

1.50

1-1/2

VTWS-224

VS-224

7340

32648

4-7/32

107.2

3/4

19.1

3-1/4

82.6

5-19/32

142.1

2-3/4

69.9

1-15/16

49.2

1-1/8

28.6

1-15/16

49.2

1-3/16

30.2

2-1/16

52.4

4

101.6

4-1/2

114.3

2-1/8

54.0

2-3/16

55.6

2-1/32

51.6

11/16

17.5

5.0

2.27

1-5/8

1-11/16

1-3/4

VTWS-226

VTWS-227

VTWS-228

VS-226

VS-227

VS-228

7901

35144

4-3/8

111.1

3/4

19.1

3-1/4

82.6

5-3/4

146.1

2-3/4

69.9

1-15/16

49.2

1-1/8

28.6

1-15/16

49.2

1-3/16

30.2

2-19/64

58.3

4

101.6

4-1/2

114.3

2-1/8

54.0

2-1/4

57.2

2-1/8

54.0

11/16

17.5

5.6

2.54

1-15/16

VTWS-231

VS-231

7889

35090

4-17/32

115.1

3/4

19.1

3-3/8

85.7

5-29/32

150.0

2-3/4

69.9

1-15/16

49.2

1-1/8

28.6

2-1/32

51.6

1-9/32

32.5

2-15/32

62.7

4

101.6

4-1/2

114.3

2-1/8

54.0

2-5/16

58.7

2-7/32

56.4

11/16

17.5

5.8

2.63

2

2-3/16

VTWS-232

VTWS-235

VS-232

VS-235

9752

43377

5-3/32

129.4

1

25.4

3-3/4

95.3

6-27/32

173.8

3-5/8

92.1

2-1/2

63.5

1-3/8

34.9

2-3/16

55.6

1-5/16

33.3

2-23/32

69.1

5-1/8

130.2

5-3/4

146.1

2-1/2

63.5

2-9/16

65.1

2-17/32

64.3

1-1/16

27.0

8.4

3.81

2-7/16

VTWS-239

VS-239

11789

52437

5-1/2

139.7

1

25.4

4

101.6

7-1/4

184.2

3-5/8

92.1

2-1/2

63.5

1-3/8

34.9

2-9/16

65.1

1-9/16

39.7

2-63/64

75.8

5-1/8

130.2

5-3/4

146.1

2-1/2

63.5

2-27/32

72.2

2-21/32

67.5

1-1/16

27.0

9.3

4.22

对于高速或高振动应用， 不推荐采用半夹头固定螺钉
和锁紧丝系统。 对于具体情况， 可与应用工程部联
系。 在此布置方式中， 只能使用一个半夹头固定螺
钉。 不应安装其它固定螺钉。 半夹头固定螺钉的凸块
应嵌入到轴槽中， 而不应紧固到轴中。
