VTWE-231、VTWE-235偏心锁定

孔径

型号

轴承芯-件编号

基本动态

额定载

荷磅/牛

尺寸（英寸/毫米）VTWE 200 系列标准型宽槽滑块单元 － 偏心锁定

重量

磅/

公斤

A

B

C

D

F

G

H

芯

J

K

L

N

O

P

毂

R

S

T

英寸

3/4

VTWE-212

VE-212

2611

11614

3

76.2

5/8

15.9

2-1/4

57.2

4

101.6

1-7/8

47.6

1-1/4

31.8

3/4

19.1

1-23/32

43.7

1-3/64

26.6

1-5/16

33.3

3

76.2

3-1/2

88.9

1-3/8

34.9

1-7/16

36.5

1-9/16

39.7

17/32

13.5

1.8

.82

7/8

15/16

1

VTWE-214

VTWE-215

VTWE-216

VE-214

VE-215

VE-216

2801

12459

3-5/64

78.2

5/8

15.9

2-1/4

57.2

4-3/32

104.0

1-7/8

47.6

1-1/4

31.8

3/4

19.1

1-3/4

44.5

1-1/16

27.0

1-1/2

38.1

3

76.2

3-1/2

88.9

1-1/2

38.1

1-9/16

39.7

1-17/32

38.9

17/32

13.5

1.9

.86

1-1/8

1-3/16

VTWE-218

VTWE-219

VE-218

VE-219

4381

19487

3-3/8

85.7

3/4

19.1

2-1/2

63.5

4-5/8

117.5

2-1/8

54.0

1-7/16

36.5

7/8

22.2

1-29/32

48.4

1-3/16

30.2

1-3/4

44.5

3-1/2

88.9

4

101.6

1-3/4

44.5

1-25/32

45.2

1-19/32

40.5

17/32

13.5

2.8

1.27

1-1/4

1-3/8

1-7/16

VTWE-220

VTWE-222

VTWE-223

VE-220

VE-222

VE-223

5782

25718

3-3/4

95.3

3/4

19.1

2-3/4

69.9

5

127.0

2-1/8

54.0

1-7/16

36.5

7/8

22.2

2-1/64

51.2

1-9/32

32.5

2-3/16

55.6

3-1/2

88.9

4

101.6

1-3/4

44.5

2

50.8

1-3/4

44.5

17/32

13.5

3.5

1.59

1-1/2

VTWE-224

VE-224

7340

32648

4-7/32

107.2

3/4

19.1

3-1/4

82.6

5-19/32

142.1

2-3/4

69.9

1-15/16

49.2

1-1/8

28.6

2-7/32

56.4

1-3/8

34.9

2-3/8

60.3

4

101.6

4-1/2

114.3

2-1/8

54.0

2-3/16

55.6

2-1/32

51.6

11/16

17.5

5.2

2.36

1-5/8

1-11/16

1-3/4

VTWE-226

VTWE-227

VTWE-228

VE-226

VE-227

VE-228

7901

35144

4-3/8

111.1

3/4

19.1

3-1/4

82.6

5-3/4

146.1

2-3/4

69.9

1-15/16

49.2

1-1/8

28.6

2-7/32

56.4

1-3/8

34.9

2-1/2

63.5

4

101.6

4-1/2

114.3

2-1/8

54.0

2-1/4

57.2

2-1/8

54.0

11/16

17.5

5.8

2.63

1-15/16

VTWE-231

VE-231

7889

35090

4-17/32

115.1

3/4

19.1

3-3/8

85.7

5-29/32

150.0

2-3/4

69.9

1-15/16

49.2

1-1/8

28.6

2-15/32

62.7

1-1/2

38.1

2-3/4

69.9

4

101.6

4-1/2

114.3

2-1/8

54.0

2-5/16

58.7

2-7/32

56.4

11/16

17.5

6.1

2.77

2

2-3/16

VTWE-232

VTWE-235

VE-232

VE-235

9752

43377

5-3/32

129.4

1

25.4

3-3/4

95.3

6-27/32

173.8

3-5/8

92.1

2-1/2

63.5

1-3/8

34.9

2-13/16

71.4

1-23/32

43.7

3

76.2

5-1/8

130.2

5-3/4

146.1

2-1/2

63.5

2-9/16

65.1

2-17/32

64.3

1-1/16

27.0

8.7

3.95

2 7/16

VTWE -239

VE -239

11789

5-1/2

139.7

1

25.4

4

101.6

7-1/4

184.2

3-5/8

92.1

2-1/2

63.5

1-3/8

34.9

3-1/16

77.8

1-27/32

46.8

3-3/8

85.7

5-1/8

130.2

5-3/4

146.1

2-1/2

63.5

2-27/32

72.2

2-21/32

67.5

1-1/16

27.0

9.6

4.35

52437

在轴承座中安装轴承单元
在轴承座面上施力（对于ER型轴承， 应在外圈面上施力） ，
把轴承压入轴承座中。
